Tekniset tiedot
Product properties
Product type Data cable preassembled
Sensor type Ethernet
Number of positions 8
No. of cable outlets 1
Cable outlet straight
Insulation characteristics
Degree of pollution 2
Electrical properties
Rated voltage (III/3) 72 V (DC)
Transmission medium Copper
Transmission characteristics (category) CAT5 (IEC 11801:2002)
Mechanical properties
Mechanical data
Insertion/withdrawal cycles ≥ 750
Material specifications
Flammability rating according to UL 94 V2
Connector
Connection 1
Type Plug straight RJ45
Handle color gray
Material CuSn (Contact)
Ni/Au (Contact surface)
PC (Contact carriers)
PA (Housing)
Insertion/withdrawal cycles ≥ 750
Degree of protection IP20
Connection 2
Type Plug straight RJ45
Handle color gray
Material CuSn (Contact)
Ni/Au (Contact surface)
PC (Contact carriers)
PA (Housing)
Insertion/withdrawal cycles ≥ 750
Degree of protection IP20
Cable/line
Cable length 0.30 m
Ethernet flexible CAT5, 4-pair, SF/UTP [94Z]
Shielded yes
Cable type Ethernet flexible CAT5, 4-pair, SF/UTP
Cable type (abbreviation) 94Z
Signal type/category Ethernet CAT5 (IEC 11801), 1 Gbps
Cable structure 4x2xAWG26/7, SF/UTP
External cable diameter 6.2 mm ±0.2 mm
Outer sheath, material PUR
External sheath, color water blue RAL 5021
Conductor material Bare Cu litz wires
Conductor structure signal line 7x 0.16 mm
AWG signal line 26
Conductor cross section 4x 2x 0.14 mm²
Material wire insulation PE
Thickness, insulation 0.19 mm (Signal line)
Wire diameter incl. insulation 0.92 mm
Single wire, color white/blue-blue, white/orange-orange, white/green-green, white/brown-brown
Twisted pairs 2 cores to the pair
Overall twist 4 pairs
Shielding Tinned copper braided shield
Optical shield covering 85 %
Test voltage Core/Core 700 V (50 Hz, 1 min.)
Test voltage Core/Shield 700 V (50 Hz, 1 min.)
Cable resistance ≤ 290 Ω/km (at 20 °C)
Cable insulation resistance ≥ 500 MΩ*km (at 20 °C)
Wave impedance 100 Ω ±15 Ω (at 100 MHz)
Smallest bending radius, fixed installation 51.2 mm
Smallest bending radius, movable installation 51.2 mm
Halogen-free according to IEC 60754-1
Resistance to oil in accordance with DIN EN 60811-2-1
Flame resistance IEC 60332-1-2
Environmental and real-life conditions
Ambient conditions
Degree of protection IP20
Ambient temperature (operation) -20 °C … 70 °C (RJ45 connector)
Muut tiedot
Tuotenumero 1423032
Pakkausyksikkö 1 Kappaletta
Tuoteavain ABNABM
Tuotekoodi ABNABM
GTIN 4055626323732
Paino kappaletta kohti (sis. pakkauksen) 39,9 g
Paino kappaletta kohti (ilman pakkausta) 38 g
Tullitariffinumero 85444210
Alkuperämaa CN
