Tekniset tiedot
Product properties
Type RJ45
Product type Female insert
Sensor type Ethernet
Number of positions 8
Connection profile RJ45
No. of cable outlets 1
Number of slots 1
Protective cover yes
Shielded yes
Cable outlet straight
Insulation characteristics
Overvoltage category III
Electrical properties
Rated voltage (III/3) 72 V (DC)
Rated surge voltage 0.8 kV
Frequency range 500 MHz
Insulation resistance > 500 MΩ (100 V DC)
Transmission medium Copper
Transmission characteristics (category) CAT6A
Power transmission PoE+
Connection data
Connection technology
Connection method IDC connection
Material specifications
Housing surface material metal-plated
Contact material Copper alloy
Contact surface material Gold
Contact carrier material PC
Material, protective cover PC
Housing material Metal
Cable/line
External cable diameter () 4.5 mm … 9 mm
Wire diameter 0.4 mm … 0.65 mm
Wire diameter including insulation 0.8 mm … 1.6 mm
Mechanical properties
Mechanical data
Insertion/withdrawal cycles ≥ 750
Test for conductor damage and slackening
Environmental and real-life conditions
Ambient conditions
Degree of protection IP20
IP20
Ambient temperature (operation) -25 °C … 70 °C
Ambient temperature (storage/transport) -40 °C … 70 °C
Mounting
Mounting type Snap in
Connection method IDC connection
Muut tiedot
Tuotenumero 1417274
Pakkausyksikkö 1 Kappaletta
Tuoteavain ABNACA
Tuotekoodi ABNACA
GTIN 4055626251424
Paino kappaletta kohti (sis. pakkauksen) 19,118 g
Paino kappaletta kohti (ilman pakkausta) 19,118 g
Tullitariffinumero 85366990
Alkuperämaa PL
